FEEO 80A Four Pole 1000V DC MCCB
₹5,400.00
This Moulded Case Circuit Breaker is designed to distribute power and protect the circuitand power equipment against overload in a solar solution. Products are designed according to IEC60947-2, GB14048.2 standards.
3 in stock
Size: 4P 1000V DC MCCB
Specifications Of FEEO 80A 4P 1000V DC MCCB
| Rated Current | 800A |
| Pole | 4P |
| Rated Operating Voltage (Ue) | 1000V |
| Rated Insulation Voltage | 1000V |
| Uimp (kV) | 8kV |
| Test Voltage One Minute (V) | 3550V |
| Breaking Capacity (kA) Icu | L 25, M 10, H 50 |
| Mechanical Life | 7000 |
| Electrical Life | 2000 |
| Breaking Times (ms) | 20 |
| Installation Location | Any Place |
| Isolator Capacity | Yes |
| Standard | IEC 60947-2, IEC60947-1, GB 14048.1, GB 14048.2 |
| Temperature (C) | -25°C ~+50°C |
| Protection Degree | IP20 |
| Accessory | OF/SD/MX |
| Arcing Distance (mm) | ≥50 |
*Product specifications subjected to change in future without further notice
For wiring diagram, please click on link below:
Put more question answers here…
Comes with 6 months warranty from the date of purchase. For more details, please contact us at contact@flinenergy.com.
